KIA EV3
Real Range Estimation
between 325 - 670 km
City: 670 km
Highway: 420 km
Combined: 525 km
Battery
Nominal Capacity 81.4 kWh
Battery Type Lithium-ion
Number of Cells No Data
Architecture 400 V
Warranty Period 7 years
Warranty Mileage 150,000 km
Useable Capacity* 78.0 kWh
Cathode Material NCM
Pack Configuration No Data
Nominal Voltage 343 V
Form Factor No Data
Name / Reference No Data
Charging
Home / Destination
Charge Port Type 2
Port Location Right Side - Front
Charge Power 11 kW AC
Charge Time (0->455 km) 8h30m
Charge Speed 55 km/h
Fast Charging
Charge Port CCS
Port Location Right Side - Front
Charge Power (max) 135 kW DC
Charge Power (10-80%) 105 kW DC
Charge Time (45->364 km) 33 min
Charge Speed 570 km/h
Autocharge Supported Yes
Plug & Charge
Plug & Charge Supported Yes
Supported Protocol ISO 15118-2
Battery Preconditioning
Preconditioning Possible Yes
Automatically using Navigation Yes
Performance
Acceleration 0 - 100 km/h 7.7 sec
Top Speed 170 km/h
Electric Range 455 km
Total Power 150 kW (204 PS)
Total Torque 283 Nm
Drive Front
Safety (Euro NCAP)
Safety Rating
Adult Occupant 83%
Child Occupant 84%
Rating Year 2025
Vulnerable Road Users 77%
Safety Assist 67%
Dimensions and Weight
Length 4300 mm
Width 1850 mm
Width with mirrors No Data
Height 1560 mm
Wheelbase 2680 mm
Weight Unladen (EU) 1885 kg
Gross Vehicle Weight (GVWR) 2355 kg
Max. Payload 545 kg
Cargo Volume 460 L
Cargo Volume Max 1251 L
Cargo Volume Frunk 25 L
Roof Load 80 kg
Tow Hitch Possible Yes
Towing Weight Unbraked 750 kg
Towing Weight Braked 1000 kg
Vertical Load Max 100 kg
Miscellaneous
Seats 5 people
Isofix Yes, 2 seats
Turning Circle 10.4 m
Platform HMG E-GMP
EV Dedicated Platform Yes
Car Body SUV
Segment JB - Compact
Roof Rails Yes
Heat pump (HP) Varies by country
HP Standard Equipment No, optional
