VOLVO EX40
Real Range Estimation
between 170 - 350 mi
City: 350 miles
Highway: 210 miles
Combined: 270 miles
Battery
Nominal Capacity 82.0 kWh
Battery Type Lithium-ion
Number of Cells 324
Architecture 400 V
Warranty Period 8 years
Warranty Mileage 100,000 mi
Useable Capacity 79.0 kWh
Cathode Material NCM
Pack Configuration 108s3p
Nominal Voltage 400 V
Form Factor Pouch
Name / Reference No Data
Charging
Home / Destination
Charge Port Type 2
Port Location Left Side - Rear
Charge Power † 11 kW AC
Charge Time (0->235 mi) † 8h30m
Charge Speed † 28 mph
Rapid Charging
Charge Port CCS
Port Location Left Side - Rear
Charge Power (max) 205 kW DC
Charge Power (10-80%) 125 kW DC
Charge Time (23->188 mi) 28 min
Charge Speed 350 mph
Autocharge Supported Yes
Plug & Charge
Plug & Charge Supported Yes
Supported Protocol ISO 15118-2
Battery Preconditioning
Preconditioning Possible Yes
Automatically using Navigation Yes
Performance
Acceleration 0 - 62 mph 4.6 sec
Top Speed 112 mph
Electric Range * 235 mi
Total Power 325 kW (436 hp)
Total Torque 494 lb-ft
Drive AWD
Dimensions and Weight
Length 4440 mm
Width 1863 mm
Width with mirrors 2034 mm
Height 1652 mm
Wheelbase 2702 mm
Weight Unladen (EU) 2170 kg
Gross Vehicle Weight (GVWR) 2650 kg
Max. Payload 555 kg
Cargo Volume 410 L
Cargo Volume Max 1286 L
Cargo Volume Frunk 31 L
Roof Load 75 kg
Tow Hitch Possible Yes
Towing Weight Unbraked 750 kg
Towing Weight Braked 1800 kg
Vertical Load Max 100 kg
Miscellaneous
Seats 5 people
Isofix Yes, 2 seats
Turning Circle 11.4 m
Platform Volvo CMA
EV Dedicated Platform No
Car Body SUV
Segment JC - Medium
Roof Rails Yes
Heat pump (HP) Yes
HP Standard Equipment Yes
